14
Control buttons
Mounting the duct cover
Position the duct cover over the mounted hood.
Slide the bottom of the duct onto the glass area.
Position the top of the duct over the duct
mounting bracket. If a telescopic duct cover is
used, grab the upper part of the telescopic duct
cover, pull it and place it in the duct cover
mounting bracket.
Secure the top of the duct with 2 assembly
screws provided. •
•
•
•
Remove Protective
Secure the bottom of the duct with 2 assembly
screws provided.
Install the grease filter and turn power on at service
panel. Check operation of the hood.
•
