57
Installation - Fig. 7
This cooker hood is designed to be fitted to a cabinet or similar
support.
• Create an opening in the bottom of the cabinet to insert the cooker
hood (1-2).
• Make a hole on the top of the cabinet to fit the hose and for the
electrical cable (3).
• Fit a hose (4) long enough to reach the outside (if the hood is used
in the extractor version) or the top of the cabinet (if the hood is used
the hood in the recirculation version).
• Remove the frame by pushing the two side release keys (5-6).
• Fix the coupling ring on the exhaust hole of the hood and make
connection with the bottom end of the hose (7a-b), seal with tape.
• Prepare the electrical connection (8).
• Fit the hood into the opening and fix securely to the cabinet with 8
screws (9).
• Fit the frame (10 - snap into place).
