56

Technical Details

Model

HL 7275

DL 7275

Dimensions:

Height

252 mm

Width

724 mm

Depth

289 mm

Maximum absorbed power:

240 W

Motor absorption:

200 W

Lighting:

2 x 20 W

Electrical connection

220-240 V

Length of the cable:

150 cm

Fuse rating:

13A 250V

Mounting accessories included

8 screws 2,9 x 16

1 Coupling ring (+ 2 screws 3.5 x 9,5)

1 Multiconnector 150-125-120

Electrical connection for UK only

Safety warnings for the electrician

Connect the hood to the mains supply via a double pole switch which

has 3 mm minimum separation between the contacts.

The switch must be accessible at all times.

The following is valid in the United Kingdom only:

- the wire which is coloured green and yellow must be connected to

the terminal which is marked with the letter E or by the earth symbol

( ), or coloured green or green and yellow;

- the wire which is coloured blue must be connected to the terminal

which is marked with the letter N or coloured black, -

- the wire which is coloured brown must be connected to the terminal

which is marked with the letter L or coloured red.
