41
Settings in bolface are the default factory settings .
Installing the VGA card retainer
To maintain the stability of the VGA card connection to the mainboard,
please check if a VGA card retainer is installed on your system. If the
card retainer is not present, refer to the instructions below for the
installation process:
Note: The VGA card retainer is included in your system’s package
contents. If it is missing or damaged, contact your computer
dealer immediately.
U6 CPU 1 socket
U10 VIA Pro266T chipset (VT8653, north bridge)
U14 CPU 2 socket
U22 Flash ROM (BIOS)
U23 Intel® 82550 LAN chipset
U32 VIA Pro266T chipset (VT8233, south bridge)
U44 Super I/O chipset (SMSC 47M102)
U47 SCSI chipset (Adaptec AIC-7899W)
Item Description
