- 11 -
Specifications
Model VS-0404
PC - Monitor Connection 4 - 4
Connectors Out 4 x HDB-15 (female)
4 x 3.5mm Mini Stereo (female)
In 4 x HDB-15 (male)
4 x 3.5mm Mini Stereo (female)
Power DC Jack
LEDs Power 1 (blue)
Source 4 (green)
Input 4 x 4 (green)
Port Selection Switches 4
VGA Resolution 1920 x 1440@60Hz
VGA DDC2B Support All Ports
Signal Type VGA / SVGA / XGA
Sync Range Sync Positive/Negative
Power Supply DC 5.3V; 2.4A
Power Consumption DC 5.3V; 12W
Cable Distance 65 meters maximum (VS-0404 to monitor)
Environment Operating Temp 0°~ 50°C
Storage Temp -20°~ 60°C
Humidity 0 ~ 80% RH, Non-condensing
Physical
Properties Housing Metal
Weight 0.89 kg
LxWxH 26.0 x 7.5 x 4.5 cm
