Operators Manual
ALS 330/430
Release 4/06 Page 77 Technical specification
10. Technical specification
The following data are maximum values. Depending on label material, operation environment
and labelling condition the real value could be lower.
10.1 Technical Information
Details
Description
330 430
Label width
(incl. backing paper)
10 mm ... 100 mm 10 mm ... 230 mm
Label length 5 to 999 mm
Diameter Label roll max 300 mm
Core diameter (of label
roll) 1.5" (37 mm), or 3" (74 mm) optional
Label roll unwind dancer arm controlled unwind brake, for minimum
change in web tension (Euro versions only)
Dispensing speed 0.2- 25 m/min 0.2- 18 m/min
Material transport 0.1 mm per motor step
APSF Automatic Product
Speed Follower optional Resolution: 0.1mm to 0.3 mm per pulse
Label stop accuracy +/- 0.5mm
Labels per min rate See performance charts
Rewind collapsible, i.e. can be used even for plastic backing material
Dispensing edge V-shape fixed; L - shape fixed (optional)
Versions available left and right hand
Dimensions w * h * d 560 * 630 * 340 mm 560 * 630 * 410 mm
Weight 28 kg 35 kg
Display panel 4 Digit LED display, 4 Membrane keys
Label sensor infrared photo sensor
CE- marked Confirms all relevant actual European standards
Protection class IP 41, IP54 on request
