KNOWING YOUR SEWING MACHINE —————————————————————————————————————————
16
e
Replace the bobbin cover. Put the left tab in
place (see arrow a), and then press lightly on
the right side (see arrow b) until the cover
clicks into place.
• Replace the cover so that the end of the
thread comes out from the left side of the
cover (as shown by the line in the diagram).
■ For models equipped with the quick-set bobbin
a
Raise the needle to its highest position by turning
the handwheel toward you (counterclockwise) or
press
(needle position button) (for models
equipped with the needle position button), and
raise the presser foot lever.
b
Slide the button and open the cover.
a Cover
b Slide button
c
Put the bobbin in, feed the end of the thread
through the slit, and then pull the thread to cut it.
• Only use bobbins that were designed to be
used with this machine.
a Cutter
• If the thread is not correctly inserted through
the tension-adjusting spring of the bobbin
case, it may cause incorrect thread tension
(page 31).
a Tension-adjusting spring
Memo
● The order that the bobbin thread should be
passed through the bobbin case is indicated
by marks around the bobbin case. Be sure
to thread the machine as indicated.
d
Replace the bobbin cover. Put the left tab in
place (see arrow a), and then press lightly on
the right side (see arrow b) until the cover
clicks into place.
Memo
● You can begin sewing immediately without
drawing up the bobbin thread. If you want
to draw up the bobbin thread before you
start to sew, follow the procedure in
“Drawing up the lower thread” (page 20).
● Make sure you set the bobbin so the thread
unrolls in the right direction. If the thread unrolls
in the wrong direction, it may cause the thread
tension to be incorrect or break the needle.
1 2
CAUTION
1
1
