Interconnecting to switches
To connect a switch or hub, note the following:
1. Use a straight-through cable to connect uplink port or use a crossover cable to connect to any
port except uplink port. (Do not connect both uplink ports together, and do not use a crossover
cable to connect with the uplink port).
LED Indicators
Front Panel LED Indicators
FriendlyNET 5-port Dual-speed Ethernet Switch
PWR 1 2 3 4 5
Collision/FullDuplex
Link/Activity
FS4005P
1 2 3 4 5 Uplink
FriendlyNET 8-port Dual-speed Ethernet Switch
PWR 1 2 3 4 5 6 7 8
Collision/FullDuplex
Link/Activity
FS4008P
1 2 3 4 5 6 7 8 Uplink
Uplink Connection
FriendlyNET
8-port Dual-speed Ethernet Switch
PWR
1 2 3 4 5 6 7 8
Collision/FullDuplex
Link/Activity
FS4008P
