Asanté FriendlyNET FS4008P Installation Guide
Page
2
Package Contents
Your switch package should contain the following:
•
The user manual
•
One 10/100Mbps switch
•
One AC power cable
•
Four self-adhesive standoffs
If any of these items are missing, contact your dealer immediately
Installation
The Asanté FriendlyNET FS4008P switch is easy to install and requires no special training. You
should, however, read the following instructions carefully before proceeding to install your switch. The
diagram below shows the layout of the front and rear panels.
Front & Rear Panel of the Asanté FriendlyNET FS4008P
FriendlyNET
8-port Dual-speed Ethernet Switch
PWR
1
2
3
4
5
6
7
8
Collision/FullDuplex
Link/Activity
FS4008P
1
2
3
4
5
6
7
8
Uplink
5VDC
