62 Chapter 6
Exploded Diagram
THE SYSTEM
LCD 14.1 ”
1. M/B to Base Assy MM25040I243 x4
SCALE 0.800
3. FDD Assy to Base Assy MM25040I243 x4
4. Top Shielding to Base Assy
MM2540I243 x3
2. I/O Nutes
MBEA1001012 x4
8. Top Assy to Base Assy MM25050IL64 x16
MM25060PCI5 x1
9. K/B to Chassis Assy MM25040I243 x3
10. LCD Module to Chassis Assy
MM25060PCI5 x4
11. Hinge Covers to Chassis Assy
MM25060PCI51 x3
12. K/B Cover to Chassis Assy
SCALE 0.800
6. Thermal to Base Assy MM20040ICI8 x4
7. Fan to Base Assy MM25060PCI51 x3
5.2 ODD to Base Assy
MM20040ICI8 x1
5.1 ODD to Base Assy
MM25040I243 x1
1
2
3
4
5
7
6
5
4
3
2
1
A B C D E F
J I H G F E D C B A
REVISIONS
LTR DESCRIPTION DATE APP
3B
3C
3D
3E
SCALE 0.700
1
LCD BRACKET-R
LCD BRACKET-L
HINGE EA1(x2)
MM25040I243 (x10)
SCREW M2.5x4.0-I(BKAG)(NYLOK)
MM25050IL64 (x4)
SCREW M2.5x5.0-I(BKI)(NYLOK)
MM20030ICI3 (x4)
SCREW M2.0x4.0-I-NI-NYLOK
SCALE 0.400
ET2T LCD ASSY(QDI 14")W/O WL
23ET2LATNS1
ET2T LCD ASSY W/O LCD(QDI)W/O WL
LCD(TFT) 14.1" QDI141X1LH03(XGA)
Acer Inc.
PART NO.
THE 3RD PROJECTION
1 PLC
G
0.25 100
H
0.10
0.15
0.20
TOLERENCE
UNIT:mm
100
50
10
RANGE
0
50
10
NAME
FINISH
MATERIAL
TOL. - +
ITEM
2
3
1
LOGO ET2S
DESCRIBTION
37ET2LATNA7
FBET2015019
AA0141X1405
PART NO.
1
2
Aspire 1310
BRAD CHIU
DESCRIPTION
DESIGNED
APPROVED
MODEL
DWG. NO.
I
23ET2LA1
J
UNIT
SCALE
DATE
2 PLC ANGLE
2003/03/24
N/S
mm
REV
DRAWN
1/1
3A
7
1
1
QTY.
1
6
2
43ET2LCTN57
ET2 LCD COVER ASSY(14")
CABLE ASSY LP141X1LH03
DD0ET1LC102
YA1 INVERTER ASSY
3HYA1IV0008
FBEA1002019
FBEA1001012
FBEA10023016
EAET1004055
LCD BEZEL ET2S
GAEA1004029
LCD RUBBER FOOT ET2T
GAEA1003022
LCD SCREW SHIELD ET2T
JXRT2004011
LCD DOWNSIDE TAPE RT2
SCALE 0.400
3
