15
5. Specifications
5.1 Communications standard category
Compliant with RS-485 and RS-232C
5.2 Communications specifications
Communications
type
RS-485 RS-232C
Compliant with RS-485 Compliant with RS-232C Network
Up to 1 pair, 31 stations 1 pair, 1 station
Information system Half duplex
Synchronization system Asynchronous
Communications
system
Transmission code ASCII code
Signal line 2-line type 3-line type (2 for transmission and
reception, and SG) Interface system
Communications speed 1,200, 2,400, 4,800 and 9,600 bps
Start bit length Fixed at 1 bit
Stop bit length Either 1 or 2 bit can be selected.
Data length Either 7 or 8 bit can be selected.
Parity No, odd or even number can be selected.
BCC check Yes or no can be selected.
Character
Communications address 1 to 99
