6. Connection
Connect the mains supply cable Live core (brown) to L and Neutral core (Blue)
to N terminal.
Connect the lighting cable Neutral core (blue) to N and Lighting Live core (brown)
to the L1 terminal on the unit as follows (see diagram D):-
LIVE (Brown)
L
NEUTRAL (Blue) N
NEUTRAL (Blue) N
LIVE (Brown) L1 Load
When wiring is complete, fit the cable clamp wiring cover to the sensor unit with
the 2 screws provided. (diagram E)
Set the two adjustment controls on the side of the unit (diagram C) to the
following positions:
TIME – Fully anti-clockwise (Test mode).
DUSK – Fully clockwise.
Push back the locating springs (diagram D) and feed the unit into the ceiling void
via the 65mm hole. The locating springs will now fold back and hold the
PDFM1500 in place.
