32W LED
FLOODLIGHT
Model: LED400FLW - White
Model: LED400FLB - Black
In
st
a
lla
tio
n
&
O
p
e
rati
n
g I
n
stru
ct
ion
s
LED400FLW.1_Instructs_147x105.indd 5,7 31/05/2012 1.57pm
Prepared by: Sally
Lamp adjustment
3 Year Guarantee
In the unlikely event of this product becoming faulty due
to defective material or manufacture within 3 years of the
date of purchase, please return it to your supplier in the
first year with proof of purchase and it will be replaced free
of charge. For years 2 and 3 or any difficulty in the first year telephone
the helpline on 020 8450 0515.
WARNING
The temperature of the lamp is very high during operation. You will get hurt
if you touch the heat sink.
High Temperature
10
20
30
40
-20
+40
10
20
30
40
The lamp can be tilted down 55 degree and pan outward 50 degree with the
spacer or 40 degrees without.
Top View
The lamp can be tilted down 55 degree pan outward 90 degree to left
The lamp can be tilted down 55 degree and
pan outward 90 degree to right.
Side View
TECHNICAL SPECIFICATIONS
Weatherproof IP55
55°
50°
Spacer
50°
Spacer
90
55°
55°
90°
90°
Supply 220 - 240V 32W
Output 2000 Lumens
