6 5
INST
ALLA
TION & OPERA
TING
INSTRUCTIONS
INFRA RED REMOTE
DIMMER SWITCH
Cat No. RLS010
3 Year Guarantee
In the unlikely event of this product becoming faulty, due to
defective material or manufacture, within 3 years of the date of
purchase, please return it to your supplier with proof of
purchase and it will be replaced free of charge.
Should you encounter any difficulty please contact
our helpline on 020 8450 0515.
Specifications
i Conforms to EC Directives: 73/23/EEC and 89/336/EEC
ii Permissible Loads: Min 40W Max 300W filament lighting
(including halogen)
iii Operating Ambient
Temperature Range: -10°C to 40°C
iv Operating Voltage: 230V AC 50Hz
v IR Range: At least 8m up to ±50°, line of sight
vi Remote Controller Batteries: 2 x AAAAlkaline
vii Fuse:
BS 1362 3A HRC ceramic
Not suitable for fluorescent low energy and discharge lighting.
Also unsuitable for flickering (neon) candle lamps.
4. Operation by remote control
Press the correct button on the remote controller briefly to turn the
lamp(s) ON or OFF. Press and hold down this button until the
correct brightness is achieved and then release.
5. Operation at the wall switch
Use the push button at the wall switch in the same way as above.
6. Troubleshooting
Symptom Cause
Power ON LED on wall switch Supply tripped or fuse blown
not illuminated (check lighting ring including
RLS010 circuit)
RLS010 fuse blown
(check RLS010 lamp circuit)
Push button on wall switch Lamp failed
not operative
Faulty RLS010
Push button on remote Incorrect channel selected
controller not operative at wall switch
Faulty RLS010
HELPLINE
020-8450-0515
For a product brochure please contact:
Timeguard Ltd.
Victory Park, 400 Edgware Road,
London NW2 6ND
020-8452-1112
or email [email protected]
