1. General:

This time switch is a compact and easy to use
segment timer module. It can control outputs of
up to 16A which makes it suitable for domestic
immersion heaters.

NTM01 – Analogue

Timer Module

ON

segment

Time

indicator

Time control segments:

1 segment = 15 minutes,

push segment down

for ON, pull up for Off.

Control switch:

1 = permanently ON,

Timer symbol = timed

control,

0 = permanently Off.

Programme

ring
