Fiberglass Cooling Towers Chapter 6: Appendix Page 24 of 25
6-3 Parts List
Figure 10: Supplied Parts for Field Assembly
Part Number Quantity Description
A0101485 1 Silicone
A0533163 110 Stainless steel flat washers, 5/16”
A0539417 55 Stainless steel screws, 5/16”-18 x 1 3/4”
A0533167 55 Stainless steel hex nut, 5/16”-18
A0534122 55 Stainless steel split lock washers, 3/8”
A0539598 40 ft. FG Tower gasketing
Figure 11: Spare Parts List
Part SF2003 c 5 SF2004 5 SF2005 d SF2007 SF2009 SF2011 SF2015
description qty Part no. qty Part no. qty Part no. qty Part no. qty Part no. qty Part no. qty Part no.
Shell, top section 1 A0533079 1 A0539552 1 A0536702 1 A0536702 1 A0535879 1 A0535879 1 A0539581
Shell, side outlet 1 A0533078 1 A0539550 1 A0536700 1 A0536700 1 A0535880 1 A0535880 1 A0539582
Shell, bottom outlet 1 A0536666 1 A0539551 1 A0536701 1 A0536701 1 A0536668 1 A0536668 1 A0539583
Tower access door 1 A0533082 1 A0533082 2 A0533082 2 A0533082 2 A0533082 2 A0533082 2 A0533082
Motor support assy. 1 A0533090 1 A0533090 1 A0536712 1 A0536712 1 A0539586 1 A0539586 1 A0539586
Fan Motor Spcr. Brkt. 1 A0539566 -- --- 1 A0536717 -- -- -- -- -- -- -- --
Fan guard 1 A0533092 1 A0533092 1 A0536706 1 A0536706 1 A0535883 1 A0535883 1 A0535883
Fan motor e 1 A0533094 1 A0539555 1 A0536709 1 A0536710 1 A0547120 1 A0547120 1 A0539577
Fan blade 1 A0533097 1 A0539556 1 A0547121 1 A0536708 1 A0541387 1 A0541387 1 A0539576
PVC fill e 10 A0533101 15 A0539557 26 A0533099 39 A0533099 32 A0533099 48 A0533099 48 A0539578
Eliminator e 5 A0533104 5 A0539558 13 A0533103 13 A0533103 16 A0533103 16 A0533103 16 A0539579
Louver 16 A0533106 16 A0539559 20 A0533106 20 A0533106 24 A0533106 24 A0533106 28 A0539580
Nozzle e 1 A0064022 4 A0539572 4 A0064022 4 A0064022 4 A0064022 4 A0064022 4 A0064022
Nozzle adaptere 1 A0101006 4 A0101006 4 A0101006 4 A0101006 4 A0101006 4 A0101006 4 A0101006
Nozzle 4 1 A0547133 4 A0547131 4 A0547131 4 A0547132 4 A0547132 4 A0547133 4 A0547133
Nozzle adapter 4 1 A0547130 4 A0547130 4 A0547130 4 A0547130 4 A0547130 4 A0547130 4 A0547130
PVC plug 6 1 A0500867 1 A0500867 2 A0500867 2 A0500867 2 A0500867 2 A0500867 2 A0500867
Flexible coupling 1 A0502553 1 A0502554 1 A0535957 1 A0535957 1 A0535957 1 A0535957 1 A0535957
Balancing valve 6 1 A0504422 2 A0504422 2 A0504422 2 A0504422 2 A0504422 2 A0504422 2 A0504422
Pressure gauge 1 A0102314 1 A0102314 2 A0102314 2 A0102314 2 A0102314 2 A0102314 2 A0102314
Strainer basket 1 A0500860 1 A0539574 1 A0535956 1 A0535956 1 A0535956 1 A0535956 1 A0535956
Float valve assy. 1 A0076209 1 A0076209 1 A0076029 1 A0538700 1 A0538700 1 A0538700 1 A0538700
Starter kit, 208 VAC 1 A0518023 1 A0518055 1 A0538701 1 A0538704 1 A0518030 1 A0518030 1 A0518059
Starter kit, 230 VAC 1 A0518024 4 A0518056 4 A0538702 4 A0538705 4 A0518031 4 A0518031 4 A0518060
Starter kit, 460 VAC 1 A0518025 4 A0518057 4 A0538703 4 A0538706 4 A0518032 4 A0518032 4 A0518061
c Fan motor spacer bracket part no. A0539566; available on FG2003 models only.
d Fan motor spacer bracket part no. A0536717; available on FG2005 models only.
e Recommended spare parts prior to April 2002.
4 Recommended spare parts list after 2002.
5 Recommended spare parts prior to February 2005 (A0504421 and A0064023)
6 Recommended spare parts list after February 2005
