Portable, Portable hot oil, Figure 1 – Sterlco Midsize User Manual
Page 12: Hot oil temperature control unit, Temperature control unit specifications
Page 12
Portable Hot Oil Temperature Control Units
Figure 1
Portable
Hot Oil Temperature Control Unit
Portable Hot Oil
Temperature Control Unit Specifications
Model
Pump
Dimensions
Shipping
Number
Available
heaters
Power
Pressure
Flow
H W D
Weight
460 / 230
6 kW 12 kW 18 kW 24 kW hp
kW PSI
Bar gpm
lpm
in. cm
in.
cm in. cm
lbs.
Kg
10
♠ Std. 9
9
1.0 0.75
30 2.07
18 68.1 46” 117 18¼” 46 42” 107 600 273
15
♠ Std. 9
9
1.5 1.12
50 3.45
18 68.1 46” 117 18¼” 46 42” 107 600 273
20
♠ Std. 9
9
2 1.49
30 2.07
24 90.8 46” 117 18¼” 46 42” 107 600 273
20
♠ Std. 9
9
2 1.49
50 3.45
24 90.8 46” 117 18¼” 46 42” 107 600 273
♠ The oil unit may be supplied with 6kW, however this will only allow the unit to attain 400°F (204°C) unassisted.
Additional piping and process load will decrease this temperature.
