Page 20 Powder Hopper Loaders
Figure 1
Typical Powder Hopper Loader
Figure 2
Powder Hopper Loader Dimensions, Specifications, and Maximum Machine-Side
Throughput
Specifications
Model Hopper capacity Full-load amps Inlet size range Shipping weight
cu. ft. Liters lbs. Kg (FLA) inches mm lbs. Kg
Powder
Hopper
Loader
1.6 45 50 22
11 1½” 38 mm
120 55
Maximum Machine-Side Throughput
Model lbs./hr. Kg/hr.
Powder Hopper
Loader
1000 454
Note: Twelve (12) -foot (3.66 m) vertical 1½” OD (approx. 38 mm)
flex hose; free-flowing powder @ 35 lbs./cu. ft. (560 Kg/cu. m)
ACS, Inc. is committed to a continuing program of product improvement.
Specifications, appearances, and dimensions are subject to change without notice.
