Figure 2 Parts of the CF3-D for duct mounting
1 Sampling probe
6 O-ring 29,2x3,53 (Factory mounted in box)
2 Sealing gasket
7 PCB (Factory supplied mounted in box)
3 Largest locking nob
8 Snap-in lid
4 2 washers
9 PG9 cable entry bushing
5 2 screws
