Seasonal Maintenance – Cleaning the Discs
When manual cleaning of the discs is required, please follow the steps described below:
Make sure that system is not under
pressure! Release the clamp and remove
the cover. (Figure 1)
Unscrew the butterfly-nut on the filtration
element. (Figure 2)
Remove the tightening cylinder. (Figure 3)
Remove the discs (for convenience we
recommend using a plastic bag). (Figure
4, 5)
Tie each set on a string and place them
in a cleaning solutions (HCL, Chlorine, or
other) refer to “Cleaning
Recommendations Clogged Filtration
Discs”.
Thoroughly wash the discs with fresh
water and then reassemble the discs on
the spines. (Figure 6)
Check that the correct quantities of discs
are assembled on the spine: when the
discs are pressed with two hands, the
top disc should be level with the
imprinted circle on the outside of the
spine. (Figure 7)
Put on the tightening cylinder and tighten
the butterfly-nut, (Figure 8,9)
Reassemble the filter cover and
tighten the clamp. (Figure 10, 11)
Figure 1 Figure 2 Figure 3
Figure 4 Figure 5 Figure 6
Figure 7 Figure 8 Figure 9
Figure 10 Figure 11
