SWITCHER
3
ABOUT YOUR SWITCHER 2
MX2106AV
2-In, 2-Out VGA+3.5mm AUDIO
Auto-Switcher
The MX2106AV is a 2-In, 2-Out VGA + 3.5mm
AUDIO Auto-Switcher. The MX2106AV
automatically switches on signal detection, but may
also be controlled manually if desired. The
MX2106AV is designed to switch VGA signals and
stereo audio.
The unit is encased in a solid metal enclosure and
ships with an external, 9V 500mA, power adapter.
Override switching is made through the INPUT
SELECT/RS-232 input. Manual override switching
is made via a contact closure on the INPUT
SELECT jack. This switch may be used for manual
control, or the contact closure may be controlled
from a control system. RS-232 control is
accomplished by sending ASCII commands to
select either Input 1 or Input 2.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION MX2106AV
Inputs Two
VGA (2) 15 Pin HD Female
Audio (2) 3.5mm Jack
Control 3.5mm Jack
Outputs Two
VGA (2) 15 Pin HD Female
Audio (2) 3.5mm Jack
Compatibility Audio + VGA thru
UXGA
Table 1. MX2106AV General
MECHANICAL MX2106AV
Material 0.1” Al
Finish Black
Height (inches) 4.40in (112mm)
Width (inches) 4.08in (104mm)
Depth (inches) 1.00in (25mm)
Weight (pounds) 0.4lbs (0.18kg)
Ship Weight (pounds) 2.0lbs (0.91kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs (min.)
Table 2. MX2106AV Mechanical
ELECTRICAL MX2106AV
Video Input Signal
Video Signal
1.5V p-p max
Video Impedance 75 Ohms
SYNC Signal TTL (+/-)
SYNC Impedance 10K Ohms
Audio Input Signal
Impedance
10K Ohms
Level 0dBU
Video Output Signals
Video Gain
1.05
Video Impedance 75 Ohms
Sync Signal TTL (+/-)
Frequency Compatibility
Horizontal
15-200 kHz
Vertical 20-190 Hz
Typical Video Bandwidth 350 MHz @ -3dB
Cross-talk -40dB @10 MHz
Coupling DC
Audio Output Signals
Impedance
75 Ohms
Gain 0dB
Power
External Power Adapter
9V 500mA (included)
Power Consumption 3 watts max.
Table 3. MX2106AV Electrical
