AUTOMATED VALVE DRAWINGS
W/ ELECTRIC ACTUATOR
C
B
SIZE
D
E
F
6
2
W/ PNEUMATIC ACTUATOR
E
D
C
F
B
SIZE
E
D
C
F
B
SIZE
W/ EXPLOSION-PROOF ELECTRIC ACTUATOR
OPEN
Size
B
C
D
E
F
1/2˝
5-3/8˝
136.5 mm
4-1/2˝
113 mm
3-5/8˝
90.7 mm
6-1/4˝
160 mm
3˝
77 mm 3/4˝
5-3/8˝
136.5 mm
4-1/2˝
113 mm
4˝
103 mm
6-1/4˝
160 mm
3˝
77 mm 1˝
5-7/8˝
149.5 mm
4-1/2˝
113 mm
4-1/2˝
115 mm
6-1/4˝
160 mm
3˝
77 mm 1-1/2˝
6-1/2˝
166 mm
4-1/2˝
113 mm
5-1/2˝
139 mm
6-1/4˝
160 mm
3˝
77 mm 2˝
6-7/8˝
174.5 mm
4-1/2˝
113 mm
6-1/4˝
158 mm
6-1/4˝
160 mm
3˝
77 mm
Size
B
C
D
E
F
1/2˝
7-3/4˝
196 mm
9-3/8˝
328.9 mm
3-5/8˝
90.7 mm
8-1/2˝
216.7 mm
5˝
125.8 mm 3/4˝
7-3/4˝
197 mm
9-3/8˝
328.9 mm
4˝
103 mm
8-1/2˝
216.7 mm
5˝
125.8 mm 1˝
8-1/4˝
209.3 mm
9-3/8˝
238.9 mm
4-1/2˝
115 mm
8-1/2˝
216.7 mm
5˝
125.8 mm 1-1/2˝
8-7/8˝
225.8 mm
9-3/8˝
238.9 mm
5-1/2˝
139 mm
8-1/2˝
216.7 mm
5˝
125.8 mm 2˝
9-1/4˝
234.3 mm
9-3/8˝
238.9 mm
6-1/4˝
158 mm
8-1/2˝
216.7 mm
5˝
125.8 mm
Size
B
C
D
E
F
1/2˝
4-1/2˝
114 mm
2-3/8˝
60.5 mm
3-5/8˝
90.7 mm
4-5/8˝
116 mm
1-3/8˝
36.5 mm 3/4˝
4-1/2˝
114 mm
2-3/8˝
60.5 mm
4˝
103 mm
4-5/8˝
116 mm
1-3/8˝
36.5 mm 1˝
5-1/2˝
139 mm
2-3/4˝
71 mm
4-1/2˝
115 mm
5-3/4˝
145 mm
1-5/8˝
41 mm 1-1/2˝
6-1/8˝
155.5 mm
2-3/4˝
71 mm
5-1/2˝
139 mm
5-3/4˝
145 mm
1-5/8˝
41 mm 2˝
6-1/2˝
164 mm
2-3/4˝
71 mm
6-1/4˝
158 mm
5-3/4˝
145 mm
1-5/8˝
41 mm
Double Acting Pneumatic Actuator
Size
B
C
D
E
F
1/2˝
5-1/8˝
126 mm
2-3/4˝
71 mm
3-5/8˝
90.7 mm
5-3/4˝
145 mm
1-5/8˝
41 mm 3/4˝
5-1/8˝
126 mm
2-3/4˝
71 mm
4˝
103 mm
5-3/4˝
145 mm
1-5/8˝
41 mm 1˝
6-1/4˝
155 mm
3-1/4˝
82 mm
4-1/2˝
115 mm
6-5/8˝
169 mm
1-3/4˝
46 mm 1-1/2˝
7-1/4˝
184.6 mm
3-3/4˝
94 mm
5-1/2˝
139 mm
7-7/8˝
201 mm
2˝
52 mm 2˝
8˝
192 mm
3-3/4˝
94 mm
6-1/4˝
158 mm
7-7/8˝
201 mm
2˝
52 mm
Spring Return Pneumatic Actuator
