Command
14
PORT
Select the correct Com. port to ensure the meter is
communicated with PC. I
For most PCs, the Com. port number is COM1.
There are 8 COM ports for selection in this software.
n connecting mode, "PC Mode"
will appear on the LCD and "COM #" & Edit will show
on the left bottom corner of screen.
Port
There are four commands in this software.
-Download measured logging data from meter to PC.
-Download measured memory data from meter to PC.
-Download measured logging & memory data from meter to PC.
-Upload pre-edited file names from PC to meter.
To edit the file names, click left key of mouse twice quickly
, then the cursor will flash to indicate the column is ready for
editing.
Before uploading or downloading, make sure you choose the
correct download mode . If you choose "Download memory
data" but execute downloading "Logger data ", you will have to
switch the mode to have the correct display.
COMMAND
