Area Adjustment (Only when Display is set to Volumetric Flow)
1. When sub-menu TYPE (next to Anemometer) is highlighted, hit the button to
access the settings sub-menu.
2. Press the arrow to scroll through the parameter headings. The currently selected
parameter will be highlighted in yellow.
3. When AREA is highlighted, press the button to enter a new submenu that allows
selection of the shape of the duct, engineering units in which the duct is measured,
and the dimensions of the duct.
4. Press the arrow to scroll through the parameter headings. The currently
selected parameter will be highlighted in yellow.
5. When the desired menu is highlighted, press the button and the current value
of the parameter will be highlighted.
6. Pressing the or buttons will cycle through the available options for each
parameter.
7. Once the desired selection is made, press button.
8. After all of the area parameters are made, press button.

Range Adjustment
1. When sub-menu TYPE (next to Anemometer) is highlighted, hit the button to
access the settings sub-menu.
2. Press the arrow to scroll through the parameter headings. The currently selected
parameter will be highlighted in yellow.
3. When RANGE is highlighted, press the button and the current minimum and
maximum of the range will be highlighted.
4. Pressing the or buttons will cycle through the available ranges.
5. Once the desired selection is made, press button.

Display Measurements

1. When MAJOR is highlighted, press the button and the measurement type
selected will be highlighted.
2. Pressing the or buttons will cycle through the available parameters.
3. Once the desired selection is made, press button.
4. In order to turn off the secondary displays, use the and to select the
measurement type that is not selected for the MAJOR display.
5. When the desired TYPE is highlighted, hit the button to access the settings
sub-menu.
6. Press the arrow to scroll through the parameter headings. The currently selected
parameter will be highlighted in yellow.
7. When VISIBLE is highlighted, press the button and either ON or OFF will be
highlighted. The measurement will be displayed when set to ON and not displayed
when set to OFF.
8. Pressing the or buttons will alternate between ON and OFF.
9. Once the desired selection is made, press button.

MAINTENANCE/REPAIR
Upon final installation of the Model VP1, no routine maintenance is required. The
Model VP1 is not field serviceable and should be returned if repair is needed. Field
repair should not be attempted and may void warranty.

WARRANTY/RETURN
Refer to “Terms and Conditions of Sales” in our catalog and on our website. Contact
customer service to receive a Return Goods Authorization number before shipping the
product back for repair. Be sure to include a brief description of the problem, plus any
additional application notes.

DWYER INSTRUMENTS, INC.

Phone: 219/879-8000

www.dwyer-inst.com

P.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A.

Fax: 219/872-9057

e-mail: [email protected]

Printed in U.S.A. 8/13

FR# 02-444116-01 Rev. 1

The measurements on the MAJOR display will always be
displayed, but the measurements on the secondary displays

can be turned off.

NOTICE
