EXAMPLE PROGRAMMING CHART
continued
MERCOID
A Division of Dwyer Instruments, Inc.
P.O. BOX 258 • MICHIGAN CITY, INDIANA 46361, U.S.A.
Phone: 219/879-8000 • Fax: 219/872-9057
www.dwyer-inst.com • e-mail: [email protected]
© Copyright 2013 Dwyer Instruments Inc. Printed in U.S.A. 5/13 FR# M1-443341-00 Rev. 3
MENU
Secure
ITEM
AL I
A Lt
A IrE
AIPi
AIiH
AIST
AILP
AL2
A2t
A2rE
A2Pi
A2iH
A2St
A2ULP
FILt
POL
POH
DEFAULT
Hi
AbS
OnOF
OFF
OFF
CLOS
O on
LO
Abs
OnOF
OFF
OFF
CLOS
Oon
3
-5.7
23.1
SET AT
Hi
AbS
OnOF
OFF
OFF
CLOS
O on
LO
Abs
OnOF
OFF
OFF
CLOS
Oon
3
0.0
25.0
DESCRIPTION
Alarm 1 Function (selectable off, lo, hi,
or hilo)
Alarm Type 1 (selectable abs
(absolute) or de (deviation))
Alarm 1 Reset (selectable onof (auto)
or hold (manual))
Alarm 1 Power Interrupt (selectable on
or off)
Alarm 1 Inhibit (selectable on or off)
Alarm 1 Output State (selectable close
or open)
Alarm 1 Lamp condition when contact
is closed (selectable on or off)
Alarm 2 function ( selectable off, lo, hi,
or hilo)
Alarm 2 Type (selectable abs
(absolute) or de (deviation))
Alarm 2 Reset (selectable onof (auto)
or hold (manual))
Alarm 2 Power Interrupt (selectable on
or off)
Alarm 2 Inhibit (selectable on or off)
Alarm 2 Output State (selectable close
or open)
Alarm 2 Lamp condition when contact
is closed (selectable on or off)
Digital Filter
Process Output Low (default is in feet)
Process Output High (default is in feet)
