A1LP
Alarm 1 Lamp: Select O on or OoFF. Factory default is O on.
O on
Alarm Lamp is ON when alarm contact is closed.
OoFF
Alarm Lamp is OFF when alarm contact is closed.
AL2
Alarm 2 function: Select OFF, Lo, Hi, or HiLo. Factory default is Lo.
OFF
Alarm 2 is disabled. No Alarm 2 menu items appear in the
Secondary or Secure menus.
Lo
Low Alarm Only. A2Lo appears in the Secondary Menu.
Hi
High Alarm Only. A2Hi appears in the Secondary Menu.
HiLo
High and Low Alarms. Both A2Lo and A2Hi appear in the
Secondary Menu, and share the same Alarm 2 Relay output.
If AL2 is set to OFFthe remaining A2, alarm 2, menu items do not appear.
A2t
Alarm 2 Type: Select AbS or dE. Factory default is AbS.
AbS
Absolute Alarm that may be set anywhere within the values of
SCALand SCAH and is independent of SP1H.
dE
Deviation Alarm that may be set as an offset from SP1H. As SP1H
is changed the Alarm Point will track with SP1H.
A2rE
Alarm 2 Reset: Select OnOF or Hold. Factory default is OnOF.
OnOF
Automatic Reset.
Hold
Manual Reset. Reset (acknowledge) by simultaneously pressing
the INDEX & DOWN ARROW keys for 5 seconds.
A2Pi
Alarm 2 Power Interrupt: Select On or OFF. Factory default is OFF.
On
Alarm Power Interrupt is ON.
OFF
Alarm Power Interrupt is OFF.
A2 iH
Alarm 2 Inhibit: Select On or OFF. Factory default is OFF.
On
Alarm Inhibit is On. Alarm action is suspended until the process
value first enters a non-alarm condition.
OFF
Alarm Inhibit is OFF.
A2St
Alarm 2 Output State: Select CLOS or OPEn. Factory default is CLOS.
CLOS
Closes Contacts at Alarm Set Point.
OPEn
Opens Contacts at Alarm Set Point.
A2LP
Alarm 2 Lamp: Select O on or OoFF. Factory default is O on.
O on
Alarm Lamp is ON when alarm contact is closed.
OoFF
Alarm Lamp is OFF when alarm contact is closed.
