MGE™ Galaxy™ 300 10-40 kVA 3:3, 10-30 kVA 3:1 - 380/400/415 V Installation 18
Battery cabling YUASA 20/30 kVA 60 min.
No. Item Description Part no. Qty.
A Battery Yuasa battery SWL 1850 910-0632 30
B Copper bar 110*25*3 880-2754 14
C Power cable Wire 16 mm
2
Ivory 380 mm 0W5032 4
D Power cable Wire 16 mm
2
Ivory 640mm 0W5035 6
E Power cable Wire Assy 16 mm 2 Ivory 1200 mm 0W5034 4
F Power cable Wire Assy 16 mm 2 red 1800 mm CB+ 0W4983 1
G Power cable Wire Assy 1 string CBN 0W4991 1
H Power cable Wire Assy 16 mm 2 White 900 mm CB- 0W4986 1
*Torque for screws to link
batteries is 4.8 Nm
