Installation
7 © 8.21
Microphone Input
Type: Electronically
balanced
Connector: Female XLR
Input Impedance >1k5
Maximum Input +20dBu
Line Input
Type: Electronically
balanced
Connector: 1 /
4
” TRS Jack Socket
Input Impedance >10k
Maximum Input +20dBu
Tape Input
Type: Electronically
balanced
Connector: 1 /
4
” TRS Jack Socket
Input Impedance >10k
Maximum Input +20dBu
Stereo Inputs
Type: Electronically
balanced
Connector: 1 /
4
” TRS Jack Socket
Input Impedance >10k
Maximum Input Level +20dBu
Play Inputs
Type: Electronically
balanced
Connector: Female XLR
Input Impedance >10k
Maximum Input +20dBu
CONNECTIONS
Insert Return
Type: Electronically
balanced
Connector: 1 /
4
” TRS Jack Socket
Input Impedance >10k
Maximum Input Level +20dBu
Insert Send
Type: Ground sensing
Connector: 1 /
4
” TRS Jack Socket
Output Impedance <75R
Maximum Output +20dBu
Auxiliary Output
Type: Electronically
balanced
Connector: Male XLR
Output Impedance <75R
Maximum Output +26dBu
Group Output
Type: Electronically
balanced
Connector: 25 Pin D-sub
Output Impedance <75R
Maximum Output +26dBu
Stereo Mix Output
Type: Electronically
balanced
Connector: Male XLR
Output Impedance <75R
Maximum Output +26dBu
All Monitoring Outputs
Type: Ground sensing
Connector: Male XLR
Output Impedance <75R
Maximum Output +20dBu
