Operation Manual
54
Specifications
©
8.21
SPECIFICATIONS
Mic input to Mix output
<+0,-0.3dB
20Hz-20kHz
@6-40dB gain.
Line input to Mix output
<+0,-0.3dB
20Hz-20kHz
@0dB gain.
THD AND NOISE AT +20dB OUTPUT
Mic XLR input to any output
<0.005% at 1kHz
Line input to any output
<0.005% at 1kHz
Tape input to any output
< 0.003% at 1kHz
NOISE
Mic EIN (20-20kHz, 150R source)
<-127.5dBu
Bus noise (no inputs routed)
<-93dBu
Bus noise (36 inputs routed)
<-78dBu
CROSSTALK AND MUTE ATTENUATION AT 1kHz
Short fader Mute
>90dB
Long fader Mute
>90dB
Mix assign
>90dB
Bus assign
>90dB
MIC CMRR
70dB (Min gain)
75dB (Max gain)
MAXIMUM INPUT
Mic
>+21dBu (min gain)
Line
>+30dBu (min gain)
insert return
>+21dBu
MAXIMUM OUTPUT INTO 2K OHMS
Mix output
>+26dBu
Bus output
>+26dBu
Aux output
>+26dBu
Insert send
>+20dBu
Monitor, Studio, F/B outputs
>+20dBu
FREQUENCY RESPONSE
