General specification, Mechanical data – Airedale Air Cooled Condensers R407C User Manual
Page 8
C11-45 / CS50 - 105
CONDENSERS
8
Condensers
Technical Manual: 6469597 V1.3.0 02_2013
General Specification
MECHANICAL DATA
C11HI
C15HI
C20HI
C25HI
C35HI
Total Heat of Rejection
(1)
kW
11
16.5
20.2
25.6
30.3
Dimensions - Horizontal
(2)
Height
mm
648
648
848
848
1048
Width
mm
550
550
645
645
645
Length
mm
1275
1275
1100
1100
1650
Dimensions - Vertical
(2)
Height
mm
997
997
1092
1092
1092
Width
mm
700
700
900
900
1100
Length
mm
1275
1275
1100
1100
1650
Weight
Machine
kg
51
63
58
65
97
Construction
Material/Colour
Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser
Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Quantity
1
1
1
1
1
Total Face Area
m²
0.675
0.675
0.8
0.8
1.6
Nominal Airflow
m³/s
1.2
1.9
2.0
2.25
2.35
Discharge
H Horizontal or V Vertical (Please Specify at Order)
Fan & Motor
Axial
Quantity
1
2
1
1
1
Diameter
mm
450
450
630
630
630
Maximum Speed
rpm
930
930
900
900
900
Refrigeration
Single Circuit
Refrigerant Type
R407C
Holding Charge
Inert Gas
Coil Volume
l
5.3
5.3
6.1
8.1
15.7
Refrigerant Charge
(3)
kg
2.1
2.1
2.3
3.1
6.1
Connections
Liquid Line - Sweat
in
1/2
1/2
5/8
5/8
7/8
Discharge Line - Sweat
in
5/8
5/8
7/8
7/8
7/8
OPTIONAL EXTRAS
Short Case Axial Fan
Designed to 75 Pa ESP
Dimensions - Horizontal
Height
mm
648
648
848
848
1048
Width
mm
675
675
735
735
711
Length
mm
1275
1275
1100
1100
1650
Dimensions - Vertical
Height
mm
1112
1112
1162
1162
1162
Width
mm
700
700
900
900
1100
Length
mm
1275
1275
1100
1100
1650
Weight
Machine
kg
61
73
70
77
109
(1)
Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2)
Overall dimensions for clearance; refer to
Dimensional & Installation Data
for detail.
(3)
For guidance only.
