Appendix A - Model Number Matrix
FIRST PEN OPTION
1 Recorder Only
4 High/Low Limit*
SECOND PEN OPTION
0 None
1 Recorder Only
4 High/Low Limit*
PEN 1 OUTPUTS
0 None
1 One Alarm Relay
2 Two Alarm Relays
PEN 2 OUTPUTS
0 None
1 One Alarm Relay
2 Two Alarm Relays
COMMUNICATIONS
0 None
1 Configurator Port
2 RS-485 Coms
3 Configurator Port &
RS-485 Coms
CASE
1 Standard - NEMA 3
2 Door Lock
3 NEMA 4X
* Does not include a relay. Order relays in output options.
** Low Voltage is 20-50 VAC or 22-65 VDC
5
SUFFIX
Blank None
AA Alarms And Communications
Connectivity Option
(Allows for later field installation
of both options)
VOLTAGE
1 Standard (100-240 VAC)
2 Low Voltage**
3 Standard Voltage Operation
and Transmitter Power Supply
4 Low Voltage Operation
and Transmitter Power Supply
5 CE
6 CE and Low Voltage
7 CE and Standard Voltage and
Transmitter Power supply
8 CE and Low Voltage and
Transmitter Power Supply
