17

Function

Settings

[Factory settings] shown in brackets

Press ▲ or ▼ to change

Press ✱ ▲ or ✱ ▼ to change

E.oP

Event output

[nonE]

Function can be applied to each
segment independently to trigger
an output at the start of that
segment for the duration of that
segment. Setting blocked unless
either or both outputs SP2A or
SP3A have been configured as an
Event Output in Level 2 or Level A
respectively.

2d

SP2A de-energised to mark event

2E

SP2A energised to mark event

3d

SP3A de-energised to mark event

3E

SP3A energised to mark event

2d.3d

SP2A and SP3A de-energised to
mark event

2E.3d

SP2A energised SP3A de-energised
to mark event

2E.3E

SP2A and SP3A energised to mark
event

2d.3E

SP2A de-energised SP3A energised
to mark event

To Return to:

LEVL P

Press and hold ▼

To Read % Programmer memory used:

USEd

Press ✱ and ▼ together in LEVL P / ProG 1

1–100%

Memory Allocation Table

Segment type

Memory required

Ramp

4 Bytes

Ramp with Holdback

5 Bytes

Soak

2 Bytes

Step

3 Bytes

Loops (1–3)

1 Byte

Loops (4+)

2 Bytes

Call

1 Byte

Event Output

1 Byte

Program Header

1 Byte

Maximum capacity:

351 Bytes

31 Programs

126 Segments

Examples:

1. 1 program of 58 Ramps and 58 Soaks

349 Bytes

2. 4 programs of 14 Ramps and 14 Soaks

340 Bytes

3. 31 programs of 2 Ramps and 1 Soak

341 Bytes

4. 2 programs of 10 Ramps, 10 Soaks, 2 Steps and 1 loop

136 Bytes

Memory Full Indication

Should the programmer memory capacity be reached during program configuration, the
display will show ‘FULL’

English
