Warren Controls 2900 Series High Capacity general purpose Globe Valves - Manual (Page 15)

15
Series 2900 IOM2900 A 1209
2900 IOM parts kits.doc
REBUILD/ REPACK KIT
FOR MODEL 29N & 291 VALVE TYPE 22
SIZE 500 & 600 (5 & 6 inch)
SEE DWG D3201752
ITEM
QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 12 1 LOWER SEAT RING
8 1 TRAVEL STOP 14 2 GASKET
9 1 GROOVE PIN 16 1 TUBE PERMATEX #2
10 1 UPPER SEAT RING 1 ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
11 1 PLUG 1 REPACK KIT
REPACK/ INSPECTION KIT
FOR MODEL 29N & 291 VALVE TYPE 22
SIZE 800 & 010 (8 & 10 inch)
SEE DWG D3201950
ITEM
QTY DESCRIPTION ITEM QTY DESCRIPTION
14 2 GASKET 1 REPACK KIT
1 ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
REBUILD/ REPACK KIT
FOR MODEL 29N & 291 VALVE TYPE 22
SIZE 800 & 010 (8 & 10 inch)
SEE DWG D3201950
ITEM
QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 14 2 GASKET
8 1 GROOVE PIN 16 1 TUBE PERMATEX #2
9 1 UPPER SEAT RING
(Valve size 8 inch) 1 ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
10 1 PLUG 1 REPACK KIT
11 1 LOWER SEAT RING
(Valve size 8 inch)
REPACK/ INSPECTION KIT
FOR MODEL 29N & 291 VALVE TYPE 23
SIZE 250 THRU 400 (2-1/2 thru 4 inch)
SEE DWG C3241354
ITEM
QTY DESCRIPTION ITEM QTY DESCRIPTION
12 3 GASKET 1 REPACK KIT
1 ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
REBUILD/ REPACK KIT
FOR MODEL 29N & 291 VALVE TYPE 23
SIZE 250 THRU 400 (2-1/2 thru 4 inch)
SEE DWG C3241354
ITEM
QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 12 3 GASKET
3 1 TRAVEL STOP (As required) 15 1 TUBE O-RING LUBE
6 1 GROOVE PIN 16 1 TUBE PERMATEX #2
8 1 O-RING 1 ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
9 1 PLUG 1 REPACK KIT
10 1 SEAT RING
parts kIts
IteM qty DescrIptIon IteM qty DescrIptIon
reBuIlD / repack kIt
for MoDel
29n & 291
valve type
22
sIZe
500
&
600
(5 & 6 Inch)
see DwG D3201752
IteM qty DescrIptIon IteM qty DescrIptIon
repack / InspectIon kIt
for MoDel
29n & 291
valve type
22
sIZe
800
&
010
(8 & 10 Inch)
see DwG D3201950
IteM qty DescrIptIon IteM qty DescrIptIon
reBuIlD / repack kIt
for MoDel
29n & 291
valve type
22
sIZe
800
&
010
(8 & 10 Inch)
see DwG D3201950
IteM qty DescrIptIon IteM qty DescrIptIon
repack / InspectIon kIt
for MoDel
29n & 291
valve type
23
sIZe
250
thru
400
(2-1/2 thru 4 Inch)
see DwG c3241354
IteM qty DescrIptIon IteM qty DescrIptIon
reBuIlD / repack kIt
for MoDel
29n & 291
valve type
23
sIZe
250
thru
400
(2-1/2 thru 4 Inch)
see DwG c3241354
*
