Thermo Fisher Scientific CyberComm 5000 for CyberScan Series 5000 - Manual (Page 20)

20
Measure - OUR (RUNNING)
z Touch to begin measurement
or
stop
Touch to access standardize mode std z
stop
mg/L/hr
0.00
STABLE
STND Not Standardized
August 12, 2002 9.32am
ID# ATC
autocal
Salinity
mg/L mmHg
25.0°C
ON 0.0 ppt
1.28 732
1:35
5.2 To export OUR Results to CyberComm 5000
Select to go to DO mode on CyberComm 5000 (See Figure 16 ), click on OUR button to display screen as
shown in Figure 17.
Figure 20: OUR Mode
From the meter
Press OUR button from the DO mode main screen to go to OUR measurement mode. Press start to start
OUR measurement. See Figure 21. Press print to export OUR results to CyberComm 5000.
Figure 21: OUR Measurement mode on meter
