Temperature
Display
Replaceable
Sensor
Twist-off
Battery
Compartment
Tester pHScan 3 pHScan 3+
pH Range 0.00 to 15.00 pH
Resolution 0.01 pH
Accuracy ±0.02 pH
Calibration USA (pH 4.01, 7.00, 10.01) or
Buffer option NIST (pH 4.01, 6.86, 9.18)
Calibration Up to 3 points
points (USA or NIST)
Temperature - 0.0 to 50.0 °C
Range
Resolution - 0.1 °C
Accuracy - ±1.0 °C
ATC 32 to 122 °F / 0 to 50 °C
Operating Temp 32 to 122 °F / 0 to 50 °C
Special On/Off; HOLD; CA (Calibrate);
Functions CO (Confirm display); auto-buffer
recognition; auto-shutoff after
8.5 min. non-use.
Power Battery Four X 1.5V (Type: A76, LR 44 or
V136A); > 150 hrs continuous use
Dimension; Tester: 16.5 cm x 3.8 cm; 90 g
Weight Boxed: 22 cm x 6 cm x 5 cm; 170g
• All push-button calibration
• Displays measured units for clarity
• Fast, stable, repeatable readings
• Available through authorized distributors
S P E C I F I C A T I O N S
Manufactured By:
Eutech Instruments Pte Ltd
Blk 55, Ayer Rajah Crescent,
#04-14/24, Singapore 139949
Tel: (65)778 6876 Fax: (65)773 0836
E-Mail: [email protected]
Web-Site: http://www.eutechinst.com
Made in Singapore
68X247824 11/00 Rev 0
REMOVE THE OLD ELECTRODE
REPLACE THE ELECTRODE
(Picture B)
(Picture A)
Electrode Replacement
You can replace the electrode module at
the fraction of the cost of a new tester.
When the tester fails to calibrate, gives
fluctuating readings in buffers,shows
error messages ‘Er1’, ‘Or’ or ‘Ur’ in a
buf fer, and the procedures in the
Maintenance section do not help, you
need to change the electrode.
1. With dry hands, grip the ribbed tester
collar with electrode facing you. Twist
the collar counter clockwise (see picture
A). Save the ribbed tester collar and
O-ring for later use.
2. Pull the old electrode module away from
the tester.
3. Align the four tabs on the new module
so that they match the four slots on the
tester (see picture B).
4. Gently push the module onto the slots
to sit it in position. Push the smaller
O-ring fully onto the new electrode
module. Push the collar over the module
and thread it into place by firmly twisting
clockwise.
Water quality testing • Pools • Spas
• Aquariums • Aquaculture • Hydroponics
• Ecology studies • Water and wastewater
treatment • Boilers • Steam generators
• Car washes • Sanitation plants
• Labs • and more!
Applications
A
B
