Techne TC-412 - Manual (Page 22)

Running Programs
Pause button Yes
Stop button Yes
End of program alarm Yes
Auto restart on power fail Yes
Interconnectivity
Connection to PC control program Yes
Software updates from Techne web-site Yes
Dimensions
Height 260mm
Width 220mm
Length 420mm
Serial Port
This socket is provided for RS232 PC link to run "Gensoft" the PC control software.
Power
Power consumption 620W
The units are voltage selectable by a slide switch. When the unit is set to 115V it will work at any
voltage between 110V and 130V. When the unit is set to 230V it will work at any voltage
between 198V and 252V.
Units marked 100V will work at any voltage between 90 and 110V.
The performance will vary and will not necessarily meet the above typical specification at the
extremes of voltage.
20
TC412 Techne Manual 19/12/08 3:37 PM Page 22
