OPERATION and TROUbLEShOOTING
OPERATION
Display. There are two lines to the display, one for flow rate
and one for accumulated total. The units used are indicated
on the display. Units are pre-ordered and factory set, and
can not be changed in the field.
If the display indicates letters and digits, the meter has
power and should be functioning normally. If there is no
display (the display is blank) the meter is not powered.
Calibration. The WMX101 is factory calibrated and should
not require any form of field calibration.
Empty Pipe Detection. All magmeters require a method
for determining that the pipe is empty, since in many cases
an empty pipe may otherwise cause a false reading. This
meter uses a software-based empty pipe detection method.
It should immediately go to a zero reading if one or more
electrodes is exposed.
Caution: There are no connections inside
the display. Breaking the seal wire will
VOID WARRANTY.
Problem Probable Cause Try...
No pulse output
Output pulses incorrect
Connect to earth ground
Note flow direction arrow,
reverse direction to meter
Change output connections
Check plumbing
Check for proper electrical wiring
Check for power across power input terminals
Reverse connections
Select another flow meter
Check for proper ground
Check for full pipe or install meter in the
vertical position
Check for proper electrical wiring
Select another flow meter
Unit not grounded
Flow reversed
Output connections reversed
Pipe not full
Excessive electrical noise
No power
Power reversed
Fluid conductivity <20 microSiemens/cm
Missing or incorrect ground wire
Empty pipe
Excessive electrical noise
Fluid conductivity <20 microSiemens/cm
