Ar ch ive d – Seametrics WMX101 User Manual
Page 3
Page 1
The WMX101 is a flanged electromagnetic flowmeter for use
in 4”, 6”, 8”, or 10” pipe in municipal or industrial water
and wastewater applications where propeller meters have
typically been used in the past. Because the WMX101 has
no moving parts, and electrodes designed to discourage
fouling, this magmeter performs well and requires much
less frequent maintenance in applications where debris
or sand would impede propeller meters. There is no rotor
to stop turning or bearings to wear out. Minimal straight
pipe requirements allow WMX101 meters to be used in
piping configurations where there is little space between
the meter and an elbow.
The WMX101 is externally powered with 12-24 Vdc. Rate
and total indication is standard. Standard solid state pulse
output allows connection to a telemetry system or a data
logger. A pulse-to-analog converter can be added if a 4-
20 mA signal is needed. A shielded (power/pulse output)
cable with DIN connection is included with the meter. The
display housing is fitted with tamper-evident features.
GENERAL INfORMATION
fEATURES
SPECIfICATIONS
DIN connector
ANSI 150 lb. drilling flanges
Cross-drilled screws for tamper-evidence
HDPE liner
Diecast-aluminum electronics housing
Rate and total indicator
316SS electrodes
4”, 6”, 8”, 10”
ANSI 150 lb. drilling flanges
150 psi working pressure
10° F to 130° F
+/-1% at 100% to 10% of reading
+/-2% at 10% of reading to cut off
4”
6”
8”
10”
12
32
60
95
500
1200
2200
3500
Welded steel, epoxy powder coated
HDPE
Diecast aluminum
316 stainless steel
Rate
Total
6
8
Gallons/Minute
Gallons x 1000
Million Gallons/Day
Gallons x 1000
Liters/Second
Cubic Meters
Liters/Second
Megaliters
Cubic Feet/Minute
Cubic Feet
12-24 Vdc, 30 mA
Current sinking pulse, opto-isolated, 24 Vdc, 10 mA max
Hardware/software, conductivity-based
NEMA 4X
Pipe Sizes
Flanges
Pressure
Temperature Range
Accuracy
Flow Range
Min
Max
Materials
Body
Liner
Electronics Housing
Electrodes
Display
Digits
Units*
Power
Output Signal
Empty Pipe Detection
Environmental
*Consult factory for additional units
Powder coated steel body
AR
CH
IVE
D
(Includes Dates Before 2/15/07)
