INSTALLATION
fULL PIPE RECOMMENDATIONS
Possible Problem:
Allows air pockets to form at sensor
Possible Problem:
Air can be trapped
better Installation:
Allows air to bleed off
better Installation:
Keeps pipe full at sensor for accuracy
Possible Problem:
Post-valve cavitation can create air pocket
better Installation:
Keeps pipe full at sensor for accuracy
