Problem Probable Cause Try...
No pulse output
Output pulses incorrect
Connect to earth ground
Note flow direction arrow,
reverse direction to meter
Change output connections
Check for proper gound
Check depth setting from
Dimension “C” table (page 6)
Select another flow meter
Install meter in the vertical position
Check chart on page 5
Unit not grounded
Flow reversed
Output connections reversed
Missing or incorrect ground wire
Incorrect depth setting
Fluid conductivity <20 microsiemans/cm
Empty pipe
Not enough straight pipe
TROUBLESHOOTING
