28

Chapter 1

Frequency variation range
(Hz)

47 - 63

Nominal voltages (Vrms)

90 - 264

Inrush current

The maximum inrush current will be less than 50A and 100A when
the adapter is connected to 100Vac(60Hz) and 240Vac(50Hz)
respectively.

Efficiency

High efficiency 85% minimum, at 100~240Vac AC input, full load,
warm-up condition.

Output Ratings (CV mode)
DC output voltage

Offers constant voltage 19.0V output source with 150W max output
power capacity.

Noise + Ripple

300mvp-pmax (20MHz bandwidth) for resistor load

Output current

0 A (min.) 3.5A (max.)

Output Ratings (CC mode)
DC output voltage

18.0 ~ 20.0

Constant output

7.9A

Dynamic Output Characteristics
Start-up time

3 sec. (@115 Vac and 230Vac full load)

Hold up time

5ms min. (@115 Vac input, full load)

Over Voltage Protection
(OVP)

25V

Short circuit protection

Output can be shorted without damage, and auto recovery

Electrostatic discharge
(ESD)

15kV (at air discharge)
8kV (at contact discharge)

Dielectric Withstand Voltage
Primary to secondary

4242 Vdc for 1 second-

Leakage current

60uA at 240Vac/60Hz

Regulatory Requirements

1. FCC class B requirements (USA)
2. VDE class B requirements (German)
3. VCCI classII requirements (Japan)

Power Management

ACPI Mode

Power Management

Mech. Off (G3)

All devices in the system are turned off completely.

Soft Off (G2/S5)

OS initiated shutdown. All devices in the system are turned off
completely.

Working (G0/S0)

Individual devices such as the CPU and hard disk may be power
managed in this state.

Sleeping State (S3)

CPU Power Down
VGA Power Down
PCMCIA Suspend
Audio Power Down
Hard Disk Power Down
Super I/O Power Down

Sleeping State (S4)

Also called Hibernate state. System saves all system states and data
onto the disk prior to power off the whole system.

AC Adapter

Item

Specification
