16
OUT:
Output. Specifies the alarm output from the camera.
ON: 5 V TTL output on.
OFF: No output
HLD:
Hold. Alarm will be held for programmed time (03 to 99 seconds).
LATCH: ON: Alarm message will remain on the screen even though alarm input
is deactivated.
OFF: Alarm message will disappear on the screen after programmed
hold time when alarm input is deactivated.
Area Title
The Area Title Setup menu enables you to label up to eight different areas for various camera
angles that the camera will view. For example, as shown in the screen below, when the camera
points to an angle between 124.3° (PAN), 30.7° (TILT) to 359.5° (PAN), 45.4° (TILT), ABC will be
displayed on the screen.
AREA TITLE SETUP
NUMBER : 01
TITLE : ABC
START ANGLE : 124.3 30.7
END ANGLE : 359.5 45.4
SWAP : OFF
SAVE AND EXIT(ESC TO CANCEL)
NUMBER:
01-16. Eight different titles are available.
TITLE:
Allows you to create a unique name for each title. Up to 12 characters.
START ANGLE:
Defines the starting point for the area title.
END ANGLE: Defines the ending point for the area title.
SWAP:
Swaps the Start and End points.
To create area titles, proceed as follows:
1. Select NUMBER and set the desired number by moving the joystick to the left or right.
2. Edit the title as described in the Titling section.
