REVO America www.revoamerica.com RELPTZ22-1
12
MOTION SETUP
SENSITIVITY : 06
POSITION : ALL
DELAY : 00 SEC
OUTPUT : OFF
HOLD TIME : 03 SEC
EXIT(ESC TO EXIT)
SENSITIVITY: 01-10. the higher the number, the greater the sensitivity.
POSITION: ALL/CENTER. Selects detection across the entire frame or just the
center.
DELAY: 0-5 sec. Sets the time the camera will wait before triggering an alarm.
OUTPUT: OFF/ON. Alarm output on or off.
HOLD TIME: 03-99 sec. Sets the time the alarm will be held.
7. To select the next page of Presets, scroll the page by moving the joystick to the left on the
first and last columns of the menu.
8. Repeat steps 2 through 7 for each additional Preset position.
9. Select EXIT and move the joystick to the right to exit, or press the ESC key.
10. Navigate to a Preset position that has been set up. Highlight the * and press the PRST key
on the keyboard controller. The camera will show the stored Preset scene as shown below.
PRESET AREA SETUP
(CTRL KEY)
NUMBER 001
PAN TILT
000.0 000.0
EXIT(ESC TO EXIT)
11. Hold down the CTRL key while selecting the desired scene with the joystick. The current
position will be displayed. Release the CTRL key to complete.
