Auto Scan
The Auto Scan Setup menu enables you to set a programmed scan of an area such as a room.
You can set the camera to start in one location and move to another location and then back to the
starting location at a preconfigured speed. Up to 5 different Auto Scans may be configured.
AUTO SCAN SETUP
NUMBER : 01
TITLE : A01
SPEED : 05 STEP
START ANGLE : ----- -----
END ANGLE : ----- -----
SCAN DIR : CCW
SWAP : OFF
DWELL : 03 SEC
SAVE AND EXIT(ESC TO CANCEL)
NUMBER: 01-04. 09 is Auto Pan mode, which will cause endless panning.
TITLE: Allows you to create a unique name for each auto scan. Up to 12
characters.
SPEED: 01-13. With 01 as the slowest speed and 13 as the fastest speed.
START ANGLE: Defines the starting point for the Auto Scan.
END ANGLE: Defines the ending point for the Auto Scan.
SCAN DIR: Defines the scan direction. CW: clockwise. CCW: counterclockwise.
SWAP: Swaps the starting and ending points.
DWELL: Sets the time that the camera stays on the start and end points before
scanning. 01-99 seconds.
To create an Auto Scan, proceed as follows:
