Revo RM185-OR1 - Manual (Page 21)

18.5”
LCD Type
18.5˝ Diagonal AM-TFT(Active-Matrix)
Pixel pitch(㎛): 300(H) x 300(V)
Brightness: 250cd/㎡(Typical)
Contrast ratio: 1000:1(Typical)
Viewing angle: 170°/160°(H/V)
Response time: 5ms(Typ., on/off)
Resolution (H x V) 1366X768@60Hz
Frequency Horizontal: 31~64kHz, Vertical: 56~75Hz
Input Signal
VGA(RGB-PC)
Audio in & out
Active Display Area (H x V) 409.8mm x 230.4mm
Packing Dimensions (W x H x D) 500mm x 375mm x 125mm (19.69” x 14.76” x 4.92”)
Weight
Monitor only: 2.47kg (5.45 Ibs)
Monitor with stand: 2.93kg (6.46 Ibs)
Gross: 4.73kg (10.43 Ibs)
Electrical Ratings DC 12V / 3A
▶▶
NOTE: Technical specifications are subject to change without notice.
- 19 -
