OSD (On Screen Display) Menu Description
All picture, sound settings and setup for the monitor can be adjusted in the OSD menu.
To adjust the OSD screen:
1. Press the MENU button to enter the OSD menu.
2. Press the ▲/▼ buttons to select the desired option. The selected option is yellow color.
3. Press the SELECT button twice to enter the sub-menu and adjust the item.
4. Change the value you wish to adjust by using the
VOL(-) & VOL(+) buttons.
5. Press the MENU button twice to exit the sub-menu and the adjusted item.
6. Press the MENU button again to exit the OSD menu.
1. Color
Option Function Value
Contrast Adjusts intensity of the image. 0 ~ 100.
Brightness Adjusts brightness of the screen. 0 ~ 100.
Color Adjust Adjusts red, green & blue color of the picture. 0 ~ 100.
Color Temp Adjusts color temperature of the picture. 9300K, 6500K, 5800K & USER.
Auto Color 1) Auto color adjustment.
Back Returns to previous menu.
