23
Telephone: (508) 678-9000 Fax: (508) 678-9447
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly
Illus. No. Part No. Qty. Description
1 100117 1 4L-620 V-Belt (motor to idler)
2 100701 1 3/16” x 3/16” x 1” Key
3 101133 1 5/8” x 2-1/4” Motor Pulley (60 Hz Only)
101130 1 5/8” x 2-1/2” Motor Pulley (50 Hz Only)
4 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
5 153002 4 5/16” Lock Washer
6 153001 4 5/16” Flat Washer
7* 100073 1 1 HP 120/208/230v 1ø 60 Hz T.E.F.C. Motor with Plug (56Z frame)
8 122701 8 Socket Terminal
122801 1 Pin/Socket Extraction Tool
9 137030 1 8-Pin Housing Connector
10 152004 4 5/16-18 Hex Nut
11 153002 4 5/16” Lock Washer
12 153001 4 5/16” Flat Washer
13 117604 4 Neoprene Sponge Tape (sold by the foot)
14 154000 4 5/16-18 Tinnerman Nut
15 800919 1 Non-Reversing Motor Mount ONLY (56Z frame)
803992* 1 1 HP 120/230v 1ø 60 Hz T.E.F.C. Motor Mount Assembly with Plug
Complete (includes illus. nos. 2 through 7 and 13 through 20)
803953 1 3/4 HP 230v 1ø 50 Hz Non-Reversing T.E.F.C. Motor Mount Assembly
Complete
(includes illus. nos. 2 through 6 and 13 through 22)
803955* 1 1 HP 230/380/460v 3ø 60 Hz Non-Reversing T.E.F.C. Motor Mount
Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
803958* 1 1 HP 230/380/460v 3ø 50 Hz Non-Reversing T.E.F.C. Motor Mount
Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
16 153051 1 3/4” S.A.E. Flat Washer
17 100603 1 16” Impellor with 3/4” Bore
18 100714 1 3/16” x 3/16” x 1-7/8” Key
19 153050 2 1/2” S.A.E. Flat Washer
20 152006 2 1/2-20 Left Hand Jam Nut
21 120200 1 3/8” x 90° Connector
22 100075* 1 1 HP 208/230/240/460v 3ø 50/60 Hz T.E.F.C. Motor
100076 1 3/4 HP 230v 1ø T.E.F.C. Motor (50 Hz Only)
* Specify voltage when ordering.
