Tumbler Bearing Assembly
Illus. No. Part No. Qty. Description
1 880220 1 1-3/4” Flange Bearing
2 153025 4 9/16” Lock Washer
3 152050 4 9/16-12 Hex Nut
4 150508 2 3/8-16 x 3/4” Hex Head Machine Bolt
5 153005 2 3/8” Lock Washer
6 152005 2 3/8-16 Hex Nut
7 150600 2 3/8-16 x 1-1/2” Hex Head Machine Bolt
8 153004 * 3/8” Flat Washer
9 153005 2 3/8” Lock Washer
10 152005 2 3/8-16 Hex Nut
11 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
12 153002 4 5/16” Lock Washer
13 153001 4 5/16” Flat Washer
14 150621 2 5/16-18 x 1-1/2” Hex Head Machine Bolt
15 152004 2 5/16-18 Hex Nut
16 801101 1 1-3/8” Bearing Box Assembly Complete
(includes illus. nos. 4 through 20)
For models mfd. without Rotational Sensor
801103 1 1-3/8” Bearing Box and Support ONLY
(includes illus. nos. 4, 5, 6, 16, and 17)
801105 1 1-3/8” Bearing Box ONLY
17 801104 1 Pillow Block Bearing Support ONLY
18 880202 1 1-3/8” Pillow Block Bearing ONLY
880779 1 1-3/8” Pillow Block Bearing Assembly with Magnet
(for models mfd. with Optional Rotational Sensor)
19 152004 2 5/16-18 Hex Nut
20 150610 2 5/16-18 x 1-1/2” Allen Setscrew
21 101100 1 18” Pulley
(for Non-Reversing Models Only)
101118 1 18-3/4” Pulley
(for Reversing Models Only)
22 101119 1 1-3/8” Taper Lock Hub (key is not included)
For Reversing Models ONLY
23 154301 2 5/16-18 x 5/16” Allen Setscrew
(for Non-Reversing Models Only)
24 100735 1 Shaft Key (for taper lock hub)
For Reversing Models ONLY
25 100108 1 5L-680 V-Belt (idler to basket [tumbler])
26 824807 1 Rotational Sensor Assembly
(for models mfd. with Optional Rotational Sensor)
* As required.
