Appendix C Performance Test Result Sheet
C-1
C Performance Test Result Sheet
Test site : Report No.
Date
Person in charge
Model MG3681A Digital Modulation Signal Generator
+ MU368060A AWGN Unit
Serial No. Ambient temperature °C
Power source frequency Hz Relative humidity %
Remarks:
Output level accuracy (Section 8.3)
Output level : –3 dBm
Measurement uncertainty : ±0.2 dB
Frequency Result Maximum Specification Value
1920 MHz
1970 MHz
2020 MHz
2070 MHz
2120 MHz
2170 MHz
Level accuracy at CW: ±3.0 dB
In-band power calculation accuracy (Section 8.4)
Output level : –3 dBm
Noise bandwidth MHz
Calculated bandwidth : MHz
Measurement uncertainty : ±0.1 dB
Frequency Result Maximum Specification Value
1920 MHz
1970 MHz
2020 MHz
2070 MHz
2120 MHz
2170 MHz
±0.6 dB when noise band-
width is
≤8 MHz
±2.0 dB when noise band-
width is
≤16 MHz
