PARTS LIST
No.
DESCRIPTION
R1
Resistor
1/2WF,
(
15MΩ)
DC 1000 V
R2
Resistor
1/4WF,
(
4MΩ) DC 250 V
R3
Resistor
1/4WF,
( 800 KΩ) DC 50 V
R4
Resistor
1/4WF,
( 150 KΩ) DC 10 V
R5
Resistor
1/4WF,
(
40KΩ) DC 2.5 V
R6
Resistor
1/2WF,
(
8KΩ) DC 0.5 V
R7
Resistor
1/2WF,
( 83.3 KΩ) AC 10 V
R8
Resistor
1/4WF,
( 360 KΩ)
AC 50 V
R9
Resistor
1/4WF,
( 1.8MΩ) AC 250 V
R10
Resistor
1/2WF,
( 6.75MΩ) AC 1000 V
R11
Resistor
1/4WF,
( 40.7 Ω) DC 2.5m A
R12
Resistor
1/4WF,
(
4 Ω) DC 25m A
R13
Resistor
1/2WF,
( 0.379 Ω) DC 250m A
R14
Resistor
1/2WF,
(
18 Ω) ΩX 1
R15
Resistor
1/4WF,
(
200 Ω) ΩX 10
R16
Resistor
1/4WF,
(
34KΩ) ΩX 1K
R18
Resistor
1/4WF,
(
240 Ω)
R19
Resistor
1/4WF,
(
44KΩ)
R20
Resistor
1/4WF,
( 195 KΩ) ΩX10K
R21
Resistor
1/4WF,
(
18KΩ)
R22
Resistor
1/4WF,
(
750 Ω)
R23
Resistor
1/4WF,
(
31KΩ)
VR1
Variable Resistor,
(
10KΩ)
D1,2,3
Diode
1N4448
C1
Ceramic Capacitor,
0.047μF50V
C2
Metal Film Capacitor,
0.047μF630V(OUTPUT)
BT1
Battery
1.5V,R6P,SUM-3 or equiv. (X2)
BT2
Battery
9V, 6F22, 006P or equiv.
F1
Fuse, Fast Acting Type,
F250V/0.5A, φ6×30mm
M
Meter Movement,
(44μA / 1.25KΩ)
BS1
Battery Contacts
(X4)
BS2
Battery Contact
(X1)
